| Name |
xLab Barcode Scanner(Wired Laser Barcode Reader) |
|---|
| Brand |
xLab |
|---|
| Model |
XBS-763L |
|---|
| Function |
1D Barcode Scan, 150 scans per sec, Two-colors LED |
|---|
| Light Source |
625 nm visible LED |
|---|
| Optical System |
2,500 pixel linear sensor |
|---|
| Microprocessor |
32 bit |
|---|
| Depth of Field |
3 mil: 0 mm
4 mil: 0 – 40 mm
5 mil: 0 – 45 mm
7.5 mil: 0 – 50 mm
10 mil: 0 – 60 mm
13 mil: 0 – 75 mm
20 mil: 0 – 90 mm |
|---|
| Scan Rate |
150 scans per second |
|---|
| Minimum Bar Width |
3 mil (Code 39) > 60% PCS |
|---|
| Print Contrast |
25% @ UPC/EAN, 100% |
|---|
| Indicator |
Two-colors LED |
|---|
| Beeper Operation |
Programmable tone & beep time |
|---|
| System Interface |
Keyboard, RS-232, HID USB, USB Virtual COM, wand, OPOS, JPOS |
|---|
| Dimensions |
161.5 × 72.5 × 55.2 mm (device only) |
|---|
| Cable |
Standard 2M straight |
|---|
| Input Voltage |
5 VDC ±5% |
|---|
| Standby Current |
55 mA typical |
|---|
| Operating Current |
90 mA (AVG), 150 mA (max.) |
|---|
| EMC |
CE & FCC DOC compliance, VCCI, BSMI |
|---|
| Operating Temperature |
0°C – 50°C (32°F – 122°F) |
|---|
| Storage Temperature |
-20°C – 60°C (-4°F – 140°F) |
|---|
| Humidity |
5% – 95% RH (non-condensing) |
|---|
| Light Level |
6, 000 Lux (fluorescence) |
|---|
| Drop Durability |
Designed to withstand 1.5M drops |
|---|
| 1D Barcode |
UPC/EAN/JAN, UPC-A & UPC-E, EAN-8 & EAN-13, JAN-8 & JAN-13, ISBN/ISSN, Code 39, Codabar, Code 128 & EAN 128, Code 93, ITF 2 of 5, IATA Code, MSI, China Postal Code, Code 32, Industrial 2 of 5, Standard 2 of 5, JAP, Code 11, GS1 DataBar, GS1 DataBar Limit |
|---|
| Remarks |
Handheld Linear Image Scanner |
|---|
| Country of Origin |
USA |
|---|
